Microscopy

Super Resolution Microscope

Nikon N-STORM Super Resolution Microscope

microscope

  • Stochastic optical reconstruction microscopy
  • Lateral resolution of ~20 nm
  • Axial resolution of ~50 nm
  • Multi-color imaging capability
  • High definition, high density images
  • NIS-Elements Software
    • Multi-channel images
    • Time lapse
    • Multipoint functionality
    • Image stitching
    • Multidimensional image display
    • 2D/3D Deconvolution
  • FRET (Fluorescence Resonance Energy Transfer) capabilities

Scanning Electron Microscope (SEM)

JEOL JSM-7500F with EDS Detector Attachment

s

  • Cold Cathode Field Emission Microscope
  • Analyses samples up to dia. = 200 mm x height = 10 mm
  • Various detectors, including:
    • LABE - STEM - EBIC - EDS
  • Cyber Enabled
  • EDS attachment can be used for elemental mapping
  • For an introduction to EDS theory and considerations for sample analysis see this video from the CMSC

*Image above taken on our instrument of diatom

Reserve Instrument SEM Image Database S.C.O.P.E. Outreach
   Stereoscopic Light Microscope

Olympus SZX7

 ltms

  • Olympus SC100 camera directly attached
  • Digital imaging
  • Live video recording
  • Images and measurements can be taken and viewed via a computer

Here are the manuals for the Microscope and Illuminator Stand and a short Video explaining the proper setup.
